Rotary Two Post Lifts

Shop Rotary 2 post lifts for quick-service, general automotive, truck, van and heavier commercial-vehicle bays, with complete lifts represented from 7,000 to 20,000 lb. The main choice is not simply capacity: compare symmetric versus asymmetric vehicle positioning, swing arms versus drive-over pads, arm reach, adapter setup, ceiling clearance and bay width. Open the guide below to see where the current Rotary two-post families fit.

SEE MORE CLOSE

Start With Vehicle Position, Arms and Pickup Points

Rotary's two-post lineup covers several different ways to engage and position a vehicle. The SPOA10 family uses an asymmetric layout, while the SPO10, SPO12, SPO16 and SPO20 families use symmetric lifting configurations. The SPOA7-MP is different again, using adjustable drive-over pads instead of conventional swing arms for faster vehicle spotting in quick-service work.

Rotary family	Rated capacity	Configuration	Why you would compare it
SPOA7-MP	7,000 lb	Asymmetric drive-over pad lift	Quick-service work where fast spotting with movable pads matters more than conventional swing-arm positioning.
SPOA10	10,000 lb	Asymmetric two-post	Compare when asymmetric vehicle positioning and door access are priorities in a general automotive bay.
SPOA10-AV	10,000 lb	Asymmetric with All-Vehicle arms	For shops that need greater pickup-point flexibility across a varied vehicle mix within the lift's rated capacity and clearances.
SPO10	10,000 lb	Symmetric two-post	A symmetric alternative in the 10K range, with arm and adapter configurations that should be matched to the vehicle mix.
SPO12	12,000 lb	Symmetric two-post	Moves into 12K service with three-stage arm and adapter configurations for larger trucks, SUVs and vans.
SPO16-AV Cargo	16,000 lb	Symmetric with Cargo AV arms	Longer arm reach and low-ceiling configurations make this family worth comparing for cargo vans and heavier mixed fleets.
SPO20	20,000 lb	Heavy-duty symmetric with TRIO arms	For the heaviest two-post applications represented here, with configurable height and width options.

Symmetric vs. Asymmetric Rotary Two Post Lifts

A symmetric lift and an asymmetric lift position the vehicle differently between the columns. That changes door clearance, arm approach and where the vehicle's center of gravity sits relative to the lift structure. It is a workflow and vehicle-fit decision, not a simple better-or-worse ranking.

The SPOA10 family is the main asymmetric choice in this collection. Rotary's SPO families, including SPO10, SPO12, SPO16 and SPO20, use symmetric lifting. Before deciding between them, check the actual vehicles' manufacturer-approved pickup points, arm reach, adapter requirements and weight distribution.

Total lift capacity does not prove vehicle fit. A vehicle can weigh less than the lift rating and still fall outside the approved arm reach, adapter setup, pickup-point geometry or per-arm loading for a specific configuration.

AV Arms, TRIO Arms and Drive-Over Pads Solve Different Problems

Arm design becomes increasingly important when one bay has to handle very different vehicles. Rotary's All-Vehicle arm systems are designed around greater reach and retraction, including access to lower or more particular pickup points. On the current 16K family, Rotary also offers longer Cargo AV Arms for longer-wheelbase cargo vehicles.

TRIO Arms use a three-stage arm with a sliding adapter so the technician can position the adapter at the pickup point without relying only on conventional arm movement. The SPO20 uses this architecture, and the collection also contains a 10K SPO10 TRIO configuration.

The SPOA7-MP takes another approach entirely. Its adjustable drive-over pads allow the vehicle to be spotted over the lift and engaged at the pad positions, making it a distinct quick-service choice rather than simply a lower-capacity version of the SPOA10.

10K, 12K, 16K or 20K?

Capacity should follow the actual vehicle mix. The 10K SPOA10 and SPO10 families cover the core of Rotary's light-duty two-post lineup represented here. The SPO12 adds capacity and longer-reaching arm configurations for larger vehicles. SPO16-AV Cargo moves further into long-wheelbase van and heavier fleet work, while the SPO20 is the highest-capacity two-post family in this collection.

Moving up in capacity also changes the physical lift. Column spacing, overall width, height, arm geometry and minimum bay requirements can increase, so buying extra capacity without checking the building can create a lift that is technically stronger but poorly matched to the bay.

Low Ceilings and Bay Dimensions

Rotary two-post lift dimensions are configuration-specific. Height and width options exist across several current families, and Rotary publishes low-ceiling configurations for heavier SPO models. The active SPO16-AV Cargo, for example, is offered in a low-ceiling format, while the SPO20 family has its own low-ceiling configuration.

Measure more than ceiling height. Check overall column width, drive-through clearance, inside-column spacing, overhead structure, vehicle roof height at full rise and the technician space needed around the bay. A lift that physically fits between the walls can still be a poor fit for the vehicles or work being performed.

Concrete, Power and Installation

Do not use one concrete requirement for every Rotary 2 post lift. Slab thickness, concrete strength, anchoring details and installation dimensions must come from the current installation documentation for the exact model and configuration being ordered.

The same rule applies to electrical requirements. Standard power and optional systems such as Shockwave can use different electrical arrangements. Confirm the selected part number, utilities and installation conditions before the lift is ordered or installation is scheduled.

Rotary Two Post Lift FAQs

What is the difference between a Rotary SPOA10 and SPO10?

Both are represented as 10,000 lb two-post lift families, but the main structural distinction is vehicle positioning. SPOA10 uses an asymmetric layout, while SPO10 uses symmetric lifting. Compare pickup points, arm and adapter configuration, door access and bay dimensions for the vehicles your shop services.

Which Rotary 10K 2 post lift should I choose?

Start with the vehicle mix rather than choosing by 10,000 lb capacity alone. SPOA10 is the asymmetric family, SPOA10-AV adds All-Vehicle arm capability, SPO10 is the symmetric family, and the SPO10 TRIO configuration changes the arm and adapter system. The best fit depends on pickup-point reach and how vehicles need to sit in the bay.

Does Rotary make a 12K two post lift?

Yes. The current GSG assortment includes SPO12 configurations rated at 12,000 lb, including symmetric models with different arm and adapter setups. Compare the exact SPO12 configuration rather than treating every 12K model as identical.

What are the concrete requirements for a Rotary 2 post lift?

Concrete requirements vary by model. Use the current Rotary installation document for the exact lift and configuration to verify slab thickness, concrete strength, anchor requirements and placement. Do not apply one model's concrete specification across the entire Rotary two-post range.

What are the dimensions of a Rotary two post lift?

There is no single dimension set. Overall height, width, column spacing, drive-through clearance and arm reach change by model and configuration. Measure the bay first, then compare those measurements with the current specification sheet for the exact lift.

How much does a Rotary 2 post lift cost?

Pricing varies by capacity, arm system, height and width configuration, power option and included equipment. Use the product grid for current pricing rather than a static collection-page amount, then confirm any required accessories and delivery costs for the exact configuration.

Are all Rotary two post lifts ALI certified?

Certification should be verified on the exact model and configuration being purchased. Rotary documents ALI certification on many of its two-post lifts, but collection membership alone should not be used as proof that every variant, accessory or unpublished configuration carries the same certification.

Choose the Lift Around the Vehicles That Use the Bay

Start with symmetric versus asymmetric positioning and the actual pickup points your technicians need to reach. Then confirm capacity, arm or pad configuration, bay dimensions, concrete, utilities and included equipment on the exact model. If a two-post layout is not the right support method for the work, compare the broader Rotary car lift lineup before committing the bay.
