Triumph NTR-24 Four-Post Lift - 24,000 lb Capacity
Your commercial fleet doesn't wait, and neither should your lift. The Triumph NTR-24 four-post lift puts 24,000 lb of lifting capacity under your heaviest trucks, buses, and fleet vehicles without forcing you into the price bracket of extreme heavy-duty equipment. It's built for shops that handle real commercial work every day, not once a month.
Nine lock positions let your techs park a vehicle at the exact height they need, whether it's a quick brake inspection or a full drivetrain teardown. The 70.8 in maximum lift height gives you serious undercarriage clearance, and the 289.9 in runway length handles extended commercial trucks and transit buses without wheel overhang. Runways adjust from 45.3 to 49.2 in between them, so you're not limited to one vehicle width.
The NTR-24 runs on 220V single-phase power, which is already in most commercial shops. No expensive three-phase conversion, no special utility work. Rugged steel construction and precision hydraulics keep this lift performing through years of high-volume service. And when you buy from Garage Supply Guys, you get direct phone support, replacement parts access, and real humans who help you troubleshoot before shipping anything.
Specifications
| Lifting Capacity | 24,000 lb |
| Per-Corner Capacity | 6,000 lb |
| Max Lift Height | 70.8 in |
| Lock Positions | 9 |
| Runway Length | 289.9 in |
| Runway Width | 24 in |
| Between Runways (Adjustable) | 45.3 to 49.2 in |
| Min Runway Height (Drive-On) | 9 in |
| Overall Height (Lowered) | 93.1 in |
| Overall Width | 150.1 in |
| Overall Length (Without Ramps) | 300 in |
| Overall Length (With Ramps) | 338.9 in |
| Width Between Columns | 131.8 in |
| Voltage | 220V Single Phase |
| Shipping Weight | 6,614 lb |
| Shipping Dimensions | 295 in L x 30 in W x 43 in H |
What's Included
- Four lift columns with hydraulic cylinders
- Two main runways with adjustable width positioning
- Hydraulic power unit with pump and motor
- Control pedal and raise/lower controls
- Safety latches and lock mechanisms (9 positions)
- Anchor bolts and fasteners for concrete installation
- Approach ramps for vehicle loading
Rolling bridge jacks (such as the RJ-9000 or RJ-15000) are available as optional accessories for wheels-free brake and suspension work. Standard color is gray steel frame.
Installation & Setup
Concrete Requirements
The NTR-24 needs a solid foundation. You're looking at 4 to 4.25 in of reinforced concrete at a minimum, with 3,000 PSI compressive strength. Anchor bolts require 3.25 in embedment depth. Stay at least 6 in from slab edges, expansion seams, and control joints. New concrete needs a full 28 days of curing before you put this lift under load. Don't install on asphalt, hand-mixed concrete, or cracked slabs.
Electrical Requirements
You'll need a dedicated 220V single-phase circuit installed by a licensed electrician. A disconnect switch within sight of the lift is required per code, and all connections must be properly grounded. Check with your local building authority on permits and inspections before installation begins.
Space Requirements
Plan for at least 10 ft of ceiling height, though 12 ft or more gives your techs comfortable workspace. The lift footprint measures 150 in wide by 300 in long without ramps. Keep 3 to 4 ft of clearance on each side for access, and ensure a level drive-on approach with at least 9 in of clearance to the runway front edge.
Professional installation is strongly recommended. At 6,614 lb, the NTR-24 requires proper rigging, anchoring, and electrical work to ensure safety compliance and warranty coverage. Contact us for referrals to certified installers in your area.
Applications
Fleet operators servicing commercial trucks and vans rely on the NTR-24 to keep vehicles moving without oversizing to more expensive heavy-duty equipment.
Professional shops performing brake, suspension, and drivetrain work on heavy-duty trucks benefit from nine lock positions and full undercarriage clearance.
Municipal and private transit operations use the NTR-24 for comprehensive maintenance on buses and large shuttle vehicles with stable, distributed support.
Dealerships handling pre-delivery inspections and warranty work on heavy commercial vehicles get the capacity they need without the footprint of heavier models.
Shops running multiple bays add the NTR-24 to handle their heaviest vehicles while lighter lifts cover the rest of the workload.
Shops expanding into commercial vehicle service gain professional-grade capacity at a more accessible entry point than the heaviest four-post models.
Shipping
Your NTR-24 ships via LTL common carrier freight with free shipping to most continental U.S. locations. Transit time ranges from 3 to 14 days depending on your location. You'll receive email notification with carrier information and tracking details upon shipment.
You're responsible for unloading the lift from the truck. At 6,614 lb, you'll need heavy machinery such as a forklift, bobcat, tractor, tow truck, or backhoe to unload and position the lift. If you don't have unloading equipment on site, we can arrange delivery to your carrier's nearest terminal for pickup with your own trailer or moving van. You're responsible for scheduling your delivery appointment with the freight company.
Free shipping excludes Government Secure Locations, State and National Parks, construction sites, islands, Alaska, and Hawaii. Additional freight fees may apply for remote areas or special routing. Need a delivery window, residential delivery, or liftgate service? Contact us before ordering so we can confirm the best delivery setup and any accessorial charges.
Warranty
1-Year Parts Warranty, No Labor
The NTR-24 includes a 1-year parts warranty covering manufacturer defects in materials and workmanship. Parts and ground shipping are provided at no charge. Troubleshooting is handled over the phone, and replacement parts ship at no cost. You or a qualified technician must install replacement parts, as labor is not covered.
Rubber lifting pads are excluded from warranty coverage. Cylinders carry a 30-day full replacement warranty. After 30 days, seal kits are available at cost for maintenance.
Warranty registration may be required after purchase. Refer to included documentation for details.
Questions Before You Buy?
Talk to our team about lifting capacity, floor requirements, installation support, vehicle fitment, or compatible rolling bridge jacks. Call (855) 498-2147.
Frequently Asked Questions
What vehicles can the NTR-24 handle?
The NTR-24 lifts up to 24,000 lb, covering commercial trucks, buses, large fleet vans, and transit vehicles. The 289.9 in runway length accommodates extended-length commercial vehicles, and the adjustable runway width (45.3 to 49.2 in between runways) fits single-axle through wide multi-axle trucks. All four wheels rest on the runways for stable, distributed support.
What are the concrete and floor requirements for installation?
You need a minimum of 4 to 4.25 in of solid, reinforced concrete with at least 3,000 PSI compressive strength. Anchor bolts embed 3.25 in deep and must be at least 6 in from slab edges, expansion seams, or control joints. New concrete must cure for 28 days before the lift operates under load. Asphalt, hand-mixed concrete, and cracked slabs are not acceptable.
What electrical setup does the NTR-24 need?
The lift requires a dedicated 220V single-phase circuit, which is standard in most commercial shops. A licensed electrician must handle the installation, including a code-required disconnect switch within sight of the lift and proper grounding on all connections. Check with your local building authority regarding permits.
How much ceiling height and floor space do I need?
Plan for at least 10 ft of ceiling height, with 12 ft or more recommended for comfortable workspace. The lift footprint is 150.1 in wide by 300 in long without approach ramps (338.9 in with ramps). Keep 3 to 4 ft of clearance on each side for technician access and ensure a level drive-on approach.
How is the NTR-24 shipped and what do I need to unload it?
The lift ships via LTL freight with free shipping to most continental U.S. locations. Transit takes 3 to 14 days. At 6,614 lb shipping weight, you'll need a forklift, bobcat, tractor, tow truck, or similar heavy machinery to unload. If you lack equipment, we can arrange terminal pickup instead.
Can I add rolling bridge jacks to the NTR-24?
Yes. Rolling bridge jacks like the RJ-9000 or RJ-15000 are available as optional accessories. They give you wheels-free lifting capability between the runways for brake, suspension, and other service work that requires removing wheels while the vehicle is on the four-post lift.
Is professional installation required?
Professional installation is strongly recommended but not strictly mandatory. The lift weighs 6,614 lb and requires precise concrete anchoring plus licensed electrical work. Proper installation ensures warranty coverage, safety compliance, and optimal performance. Contact us for referrals to certified installers in your area.
What does the warranty cover?
The NTR-24 carries a 1-year parts warranty covering manufacturer defects in materials and workmanship. Parts and ground shipping are free. Rubber lifting pads are excluded, and hydraulic cylinders have a 30-day full replacement window. After 30 days, seal kits are available at cost. Labor is not covered.
How does the NTR-24 compare to the NTR-16 and NTR-32?
The NTR-24 sits in the middle of the Triumph four-post lineup. The NTR-16 is a lighter-duty option at 16,000 lb for shops that primarily service medium commercial vehicles, while the NTR-32 steps up to 32,000 lb for the heaviest trucks and equipment. The NTR-24's 24,000 lb capacity handles the majority of commercial truck and bus work without the added cost and footprint of the NTR-32.
What lock positions are available and how do they work?
The NTR-24 offers 9 lock positions across its full lift range up to 70.8 in. Safety latches engage mechanically at each position, letting your techs secure the vehicle at the exact working height needed for any job. This flexibility means fewer compromises between tasks like general maintenance and detailed undercarriage work.
Features
Drive-On Runways
Bay Planning
Pre-Order Site Review
Specifications
| Model / Package | NTR-24 |
|---|---|
| Product Type | Four-Post Vehicle Lift |
| Rated Capacity | 24,000 lb |
|---|---|
| Maximum Lift Height | 70.8 in |
| Minimum Runway Height | 9 in |
| Overall Height | 93.1 in |
| Overall Length Without Ramps | 300 in |
| Overall Length With Ramps | 338.9 in |
| Overall Width | 150.1 in |
| Runway Size | 289.9 x 24 in |
| Power | 220V, single phase |
| Motor | 4.0 kW |
| Lock Release | Pneumatic |
