Stratus SAE-P48C 4 Post Car Lift 8000 lbs Capacity
SKU: SAE-P48C
Financing options available
Financing estimates are based on the product price; selected add-ons and delivery services are excluded.
- Authorized Stratus Auto Equipment Dealer
- Manufacturer Warrantyincluded with purchase
- Price Match Guaranteefind it lower and we will beat it
- No Sales Tax Collected Outside PAPA orders include sales tax
Stratus SAE-P48C 4-Post Parking Lift - 8,000 lb Capacity with Castors
Most garages don't have enough floor space. The Stratus SAE-P48C G3 four-post parking car lift with castors solves that problem without asking you to tear anything down. At 8,000 lbs of rated capacity, it handles everything from daily drivers to weekend project cars - and because the whole unit rolls on a castor kit, you can reposition it whenever your layout changes.
This is the third generation of the compact Stratus parking lift, and the refinements show. Nine locking positions give you real flexibility on working height. The hands-free lock release latch system means you're not fumbling with manual catches every time you lower a vehicle. And the cable failure protection adds a second automatic safety device that engages the moment your primary safety locks are out of position - not something you'd expect on a storage lift, but it's there.
The power unit is relocatable, so you're not locked into one cord-routing path across your shop floor. Finish is powder-coated Granite Gray (RAL 7026) with Rein Orange (RAL 2004) accents - it looks like a piece of equipment, not an afterthought. Every unit is proofed by dynamic test at 115% of rated capacity and static test at 150%, so the 8,000 lb rating isn't a theoretical number.
GSG stocks parts and ships nationwide. If you have fitment questions or need help confirming your ceiling clearance before ordering, call us before you buy.
Specifications
| Capacity | 8,000 lbs |
| Min Lifting Height | 5-1/8 in (130 mm) |
| Max Lifting Height | 86-5/8 in (2,200 mm) |
| Lifting Time | 50 sec |
| Clearance Height | 81-1/16 in (2,059 mm) |
| Overall Height | 97-1/2 in (2,476 mm) |
| Overall Width | 102-3/8 in (2,601 mm) |
| Overall Length (with ramps) | 207 in (5,257.5 mm) |
| Overall Length (without ramps) | 169-1/2 in (4,306 mm) |
| Width Between Columns | 83-1/8 in (2,111 mm) |
| Drive-Thru Width | 74-15/16 in (1,904 mm) |
| Runway Width | 18-11/16 in (475 mm) |
| Runway Length | 165-3/8 in (4,200 mm) |
| Space Between Runways | 37-5/8 in (955 mm) |
| Motor | 3 HP, 110V, 60 Hz, 1-phase |
| Recommended Oil | AW32 or AW46 |
| Breaker Requirement | 30A |
| Shipping Weight | 1,823 lbs |
| Shipping Dimensions | 167 in L x 22 in W x 30 in H |
| Locking Positions | 9 |
| Finish | Granite Gray (RAL 7026) + Rein Orange (RAL 2004) |
What's Included
- Rolling Jack Tray
- Castor Kit (set of 4)
- Drip Trays (3 pcs)
Optional add-ons available separately: BJ5 rolling bridge jack, aluminum ramps.
Applications
Park one vehicle on the lower level and store a second above. The compact footprint and rollable castors let you reclaim floor space without committing to a permanent installation.
When your bays are full and you need somewhere to stage a car overnight, this lift doubles your parking density without bolts in the floor.
Seasonal vehicles, project cars, or rarely driven classics stay protected up top while your daily driver sits underneath. Nine locking positions mean you can dial in exactly the height you need.
With the optional rolling bridge jack, you can do basic underbody work. This isn't a full-service lift, but for oil changes and visual inspections it gets the job done.
Product Video
Shipping
The SAE-P48C ships freight (LTL) to all 50 states. Our team coordinates the freight shipment and helps manage scheduling details. This unit ships at 1,823 lbs - it arrives on a pallet via common carrier.
Need a delivery window, residential delivery, or liftgate service? Contact us before ordering so we can confirm the best delivery setup and any accessorial charges.
Note: A surcharge applies to shipments to OR, WA, ID, MT, ND, SD, and ME. Contact us before ordering if you're in one of these states.
Upon delivery, inspect the shipment immediately. Note any damage or missing parts directly on the driver's receiving receipt and document with photos. Freight damage claims require documentation at delivery.
Warranty
5 Years - Structural components
3 Years - Hydraulic components
2 Years - Electrical components
Warranty registration may be required after purchase. Refer to included documentation for details.
Documents
Click to open in a new tab.
Questions Before You Buy?
Our team can help you confirm clearance requirements, delivery setup, and optional accessories before you order. Call us at (855) 498-2147.
Frequently Asked Questions
Does the SAE-P48C require any concrete anchoring or floor bolting?
No. The SAE-P48C is a free-standing parking lift that does not require floor anchoring. The included castor kit lets you roll the unit into position and reposition it as needed. This makes it a practical option for renters or anyone who doesn't want to modify their floor slab.
What electrical supply does this lift need?
The SAE-P48C runs on a 110V, 60 Hz, single-phase circuit. You'll need a dedicated 30A breaker. The motor is 3 HP. Most residential and commercial garages can support this without a panel upgrade, but confirm your available breaker capacity before ordering.
What's the maximum ceiling height this lift requires?
The overall height of the unit is 97-1/2 in (2,476 mm). That's the column height. The maximum lifting height is 86-5/8 in (2,200 mm), and the clearance height - the usable space under the raised platform - is 81-1/16 in (2,059 mm). You'll want to confirm your ceiling height against the overall unit height before ordering, especially if you plan to raise vehicles to full height.
How long does it take to raise a vehicle?
Lifting time is 50 seconds from lowest to full height. The nine locking positions let you stop at any intermediate height, and the hands-free lock release latch system means you don't need to manually set individual catches during descent.
Can I do oil changes or undercar work on this lift?
The SAE-P48C is primarily a storage and parking lift, not a full-service lift. For basic undercar access, the optional BJ5 rolling bridge jack (sold separately) fits the runway tray and lets you raise the axle for tire swaps and simple inspections. For heavy repair work, a two-post or four-post service lift is the right tool.
What is the weight capacity, and does it cover trucks and SUVs?
Rated capacity is 8,000 lbs. Every unit is proof-tested at 115% of rated capacity dynamically and 150% statically. Most full-size trucks and SUVs fall under 6,500 lbs GVWR, so the 8,000 lb rating covers the majority of consumer vehicles. Confirm your vehicle's GVWR against the 8,000 lb limit before use.
Does this lift ship with ramps, and what's the overall length with and without them?
Aluminum ramps are an optional add-on sold separately. Without ramps, overall length is 169-1/2 in (4,306 mm). With ramps installed, it extends to 207 in (5,257.5 mm). Plan your bay depth around both measurements depending on whether you're ordering ramps.
How is this unit delivered, and what do I need to do at delivery?
The SAE-P48C ships LTL freight at a shipping weight of 1,823 lbs. It arrives via common carrier on a pallet. You are responsible for unloading - freight carriers allow 30 minutes for unloading; time beyond that may be charged. Inspect the shipment at delivery, note any damage or missing parts on the driver's receiving receipt, and photograph everything before signing. Contact us before ordering if you need liftgate service or a delivery window.
What does the warranty cover and for how long?
The SAE-P48C carries a 5-year warranty on structural components, 3 years on hydraulic components, and 2 years on electrical components. Warranty registration may be required after purchase - refer to the included documentation for details.
