Product highlights
- 3.5 in Low Profile Access
- 3.33 Ton Rated Capacity
- Dual Pump Pistons
3.33 Ton Low Profile Service Jack, 3.5 in Minimum Height
SKU: K-63133
$446.75
Save 2% with ACH / Wire Payment. Call for details
Financing options available
Financing estimates are based on the product price; selected add-ons and delivery services are excluded.
Talk to a parts specialistFit and compatibility help before you order855-498-2147
- Price Match Guaranteefind it lower and we will beat it
- No Sales Tax Collected Outside PAPA orders include sales tax
This 3.33 ton low profile service jack reaches under low-ground-clearance vehicles with a 3.5 in minimum height and lifts to 21.375 in. Its 50 in pump handle provides reach for positioning and pumping during service work.
A dual-pump-piston power unit raises the saddle to maximum height in 8 full incremental pump strokes with no load. The load-limiting valve helps prevent use beyond rated capacity, while the bypass valve prevents ram over-extension. This jack is for lifting only; after lifting, support the vehicle with appropriately rated jack stands before working on it.
Features
3.5 in Low Profile Access
The 3.5 in minimum height provides access under vehicles with limited ground clearance.
3.33 Ton Rated Capacity
Provides a 3.33 ton lifting capacity with a lift range from 3.5 in to 21.375 in.
Dual Pump Pistons
The dual-pump-piston power unit reaches maximum saddle height in 8 full incremental pump strokes with no load.
Load and Ram Protection
A load-limiting valve helps prevent use beyond rated capacity, while a bypass valve prevents ram over-extension.
Specifications
| Product Type | Hydraulic low profile service jack |
|---|---|
| Rated Capacity | 3.33 tons |
| Brand | K-Tool (K Tool International) |
| Manufacturer Part Number | XD63133 |
| Manufacturer Designation | KTI-XD63133 |
| Common Distributor Format | KTIXD63133 |
| Store SKU | K-63133 |
| Pump System | Dual pump piston |
|---|---|
| No-Load Rise | Maximum height in 8 full incremental pump strokes |
| Load-Limiting Valve | Helps prevent use beyond rated capacity |
| Bypass Valve | Prevents ram over-extension |
| Safety Standard | Complies with ASME PASE-2014 |
| Minimum Height | 3.5 in |
|---|---|
| Maximum Height | 21.375 in |
| Overall Length | 27.5 in |
| Low Height Reach | 12.5 in |
| Overall Width | 14 in |
| Chassis Height | 6.3125 in |
| Saddle Diameter | 4-3/5 in |
| Handle Length | 50 in |
| Net Weight | 94-1/4 lbs |
|---|---|
| Gross Weight | 104 lbs |
| Warranty | 2 years against defects in material and workmanship |
