Fortisky 1660-8833 Combo 26" Swing Arm Tire Changer & 3D Radar Balancer
- Authorized Online Dealer direct manufacturer relationship
- No Sales Tax outside PA where applicable
- Authorized Dealer Price Match verification required
- Fast Delivery some products may have lead times
- Manufacturer Warranty included with purchase
- Questions? +1 (855) 498-2147
Fortisky Tire Changer and Wheel Balancer Combo: FTC-6700 + FWB-5733
Also searched as: truck tire changer wheel balancer combo / heavy duty tire equipment / commercial tire service package / bus tire changer combo
Heavy duty tire service equipment for truck, bus, and commercial fleet work. The FTC-6700 truck tire changer handles rims from 14" to 42" with joystick control and bidirectional mount/dismount head. The FWB-5733 truck wheel balancer handles wheels up to 440 lbs with an integrated pneumatic wheel lift cart. Passenger vehicle adapter included for mixed shop work.
Who It's For
Truck and Fleet Service Centers
Built for commercial vehicle work. The FTC-6700 handles truck, bus, and heavy equipment tires up to 59" diameter and 30" width. Joystick control keeps operators positioned safely during mount/dismount. Sealed gearbox and hydraulic chuck built for daily fleet volume.
Mixed Passenger/Commercial Shops
Passenger vehicle tire adapter included with the FTC-6700. The FWB-5733 balancer covers 10" to 28" rims, handling everything from passenger cars to heavy trucks. One equipment set for your entire customer base.
Agricultural and Heavy Equipment Dealers
Handles wheels up to 3,307 lbs on the tire changer, 440 lbs on the balancer. Pneumatic wheel lift cart eliminates manual lifting of heavy assemblies. Vertical column design provides clearance for large diameter tires.
FTC-6700 Truck Tire Changer
Heavy Duty Vertical Column Design
The FTC-6700 uses a vertical column layout with joystick control for all functions. Dual 1.5 kW motors power the hydraulic pump and gearbox. Bidirectional mount/dismount head works both directions for faster tire changes. Handles rims from 14" to 42" with max tire diameter of 59" and max width of 30".
Key Features
Hydraulic chuck: Safety check valve prevents wheel drops if hydraulic line breaks. Pressure relief valve: Set at 130 bar for controlled operation. Sealed gearbox: Extended gear life in demanding environments. Bead pressing roller: Scale alignment for precise positioning. Jaw protectors: Included for aluminum truck wheels. Passenger adapter: Included for mixed shop work.
FWB-5733 Truck Wheel Balancer
Heavy Duty Balancer with Wheel Lift Cart
The FWB-5733 handles wheels up to 440 lbs (200 kg) with an integrated pneumatic wheel lift cart. Rim capacity from 10" to 28", max wheel diameter 47". LED display with easy-to-read readouts. Dynamic, static, and ALU balance modes cover steel and alloy wheels.
Key Features
Wheel lift cart: Pneumatic lift raises heavy wheels to shaft height, eliminating manual lifting. Balancing precision: ±3g or better. Self-calibration: Maintains accuracy without service calls. Automatic brake: Locks wheel in position for weight placement. Low noise motor: Vibration-damping design for quieter operation.
Product Videos
FTC-6700 Truck Tire Changer
FWB-5733 Truck Wheel Balancer
Specifications
| Spec | Value |
|---|---|
| Rim Diameter | 14" - 42" |
| Max Tire Diameter | 59" (1500mm) |
| Max Tire Width | 30" |
| Max Wheel Weight | 3,307 lbs (1500kg) |
| Pump Motor | 1.5 kW |
| Gearbox Motor | 1.5 kW |
| Power | 220V/230V or 380V/440V 3-Phase |
| Weight | 1,278 lbs (580kg) |
| Spec | Value |
|---|---|
| Rim Diameter | 10" - 28" |
| Rim Width | 1.5" - 20" |
| Max Wheel Diameter | 47" |
| Max Wheel Weight | 440 lbs (200kg) |
| Precision | ±3g |
| Power | ~600W, 110V or 220V 1-Phase |
| Air Supply (Lift Cart) | 0.6 - 0.9 MPa (87-130 PSI) |
| Weight (with lift cart) | 511 lbs (232kg) |
Installation Requirements
Space
Tire Changer: Minimum 2240 x 1640mm footprint. 80cm clearance behind, 50cm on left, 200cm on right for tire handling. Wheel Balancer: Approximately 1320 x 950mm footprint plus operator clearance. Both require level, solid floors. Total combined weight approximately 1,789 lbs.
Utilities
Electrical - Tire Changer: 220V/230V three-phase or 380V/440V three-phase. Circuit breaker required (25A for 220V, 16A for 380V). Proper grounding essential.
Electrical - Wheel Balancer: 110V or 220V single-phase. Separate dedicated circuit recommended. 15A breaker with overload protection.
Air Supply: Wheel lift cart requires 0.6-0.9 MPa (87-130 PSI) with 5μm filter. Medium flux greater than 0.15 m³/min. Tire changer is hydraulic, not pneumatic.
Floor: Level concrete at least 20cm (8") thick, B25 grade or equivalent. Anchor bolts required for wheels over 500kg.
Shipping
Ships freight to lower 48 states. Free to commercial address or nearest carrier terminal. Residential, farmland, construction site, and liftgate service available for additional fee. Forklift required for unloading (combined weight nearly 1,800 lbs). Inspect both crates for damage before signing delivery receipt. Call +1 (855) 498-2147 with questions.
Warranty
Coverage
1 Year Standard: Equipment structure and all operating components on both machines. U.S. parts warehouse in Virginia Beach, VA. Direct tech support by phone. Next-day replacement parts for warranty claims.
2 Year Extended Warranty: Available at purchase for both machines.
Not covered: Normal wear, abuse, misuse, shipping damage, improper installation, voltage issues, lack of required maintenance.
Documentation
Buy the Fortisky FTC-6700 + FWB-5733 Combo
Questions about installation, power requirements, or specs?
FAQs
What size wheels can this combo handle?
Tire changer handles 14" to 42" rims with max tire diameter of 59" and max width of 30". Handles wheels up to 3,307 lbs. Balancer handles 10" to 28" rims with max wheel diameter of 47" and max weight of 440 lbs.
Can I still do passenger car tires?
Yes. The FTC-6700 includes a passenger vehicle tire adapter. The FWB-5733 balancer handles passenger, light truck, and heavy truck wheels across its full 10" to 28" rim range.
What electrical service do I need?
Tire changer requires 220V/230V or 380V/440V three-phase power with appropriate circuit breaker. Balancer runs on 110V or 220V single-phase. Both require proper grounding and dedicated circuits.
Do I need an air compressor?
Yes, for the wheel lift cart on the balancer. Air supply should be 0.6-0.9 MPa (87-130 PSI) with a 5μm filter. The tire changer itself is hydraulic, not pneumatic.
How does the wheel lift cart work?
Roll the tire onto the lift platform. Use the pneumatic valve to raise the wheel to shaft height. Align the center hole with the shaft, push onto the cone, and lock with the quick nut. Eliminates manual lifting of heavy truck wheels.
What floor requirements are there?
Level concrete floor at least 20cm (8") thick, B25 grade or equivalent. Anchor bolts required when working with wheels over 500kg. Combined equipment weight is nearly 1,800 lbs.
What's the total weight of the combo?
Approximately 1,789 lbs combined (1,278 lbs tire changer + 511 lbs balancer with lift cart). Forklift required for unloading.
What's the advantage of buying the combo?
Matched equipment from one manufacturer. Same warranty coverage, same support contact, simplified ordering and shipping. Both machines designed for the same heavy-duty commercial service environment.
