ESCO Cyclone Classic 5 Gallon Bead Seater (20380)
End discharge design for ATV to 24.5" truck tire bead seating
ASME-certified 5-gallon steel bead seating tank for professional tire shops. End discharge design provides controlled air bursts to seat stubborn tire beads on small and medium applications from ATV wheels to light truck tires. Maximum 165 PSI capacity with safety relief valve and simple valve control for repeatable results.
Key Features
End Discharge Design
Classic end discharge configuration provides stability and control while seating even difficult tire beads. Greater precision positioning compared to side discharge models.
ASME Certified Steel Tank
Heavy-duty steel construction built for commercial shop environments. ASME certification ensures safety standards and durability through daily use.
165 PSI Maximum Capacity
Tank stores air at up to 165 PSI with recommended operating range of 40-155 PSI. 160 PSI safety relief valve prevents over-pressurization.
Compact Upright Design
Dimensions of 22" x 13" x 13" fit easily in shop spaces. Weighs 34 lbs. for stable positioning during operation.
What's Included
- ESCO Cyclone Classic 5-gallon bead seating tank
- Safety glasses
- Ear protection
| Specification | Value |
|---|---|
| Brand | ESCO |
| Model | Cyclone Classic 20380 |
| SKU | ESC-20380 |
| Tank Capacity | 5 gallons |
| Material | Steel (ASME certified) |
| Maximum PSI | 165 PSI |
| Operating Pressure | 40-155 PSI |
| Relief Valve | 160 PSI safety relief |
| Weight | 34 lbs. |
| Dimensions | 22" x 13" x 13" |
| Tire Range | ATV to 24.5" truck tires |
Perfect For
- ATV and UTV tire mounting
- Golf cart tire installations
- Passenger car and small truck tire bead seating
- Light commercial vehicle tires
- Independent tire shops with high-volume mounting
Frequently Asked Questions
What tire sizes does this bead seater handle?
This 5-gallon bead seater works on tire sizes from ATV wheels up to 24.5" truck tires. It's ideal for passenger vehicles, golf carts, and light commercial applications. For extremely large truck tires or agricultural equipment, consider a larger capacity tank.
How do I know what pressure to use for bead seating?
Most applications work well in the 40-100 PSI range. Start at lower pressures for smaller tires like ATVs (40-60 PSI) and increase for larger, stiffer sidewalls. The tank's gauge allows you to monitor pressure, and the 160 PSI safety relief valve prevents over-pressurization.
Is special training required to operate this bead seater?
The ESCO Cyclone is designed for straightforward operation. Position the discharge nozzle against the tire bead, trigger the valve, and monitor the seal. Safety glasses and ear protection are included. Operating instructions come with the unit for proper safe use in a shop environment.
What's the difference between this and other bead seaters?
The Cyclone Classic features ASME certification for proven safety, an end discharge design for precision control, and heavy-duty steel construction for daily shop use. This design provides stable, repeatable bead seating compared to lighter-duty alternatives.
How do I maintain this bead seater tank?
Keep the tank dry when not in use to prevent internal corrosion. Drain any accumulated moisture from the bottom valve periodically, especially if used frequently. Check the safety relief valve and pressure gauge regularly to ensure they function properly. Store in a protected location away from weather.
