Challenger EV10CK-BMC-QC - Quick Cycle Completion Kit with Bench Mounted Controls for EV1020 Inground Lift
The Challenger EV10CK-BMC-QC Completion Kit delivers the hydraulic power unit, chrome pistons, and control components needed to complete your EV1020 10,000 lb inground lift installation. Featuring Quick Cycle performance with approximately 27 second rise time and 17 second descent, this kit combines faster lift operation with ergonomic bench mounted controls for improved technician workflow.
Key Features & Benefits
Quick Cycle Performance System
The Quick Cycle system delivers significantly faster lift operation with an approximate 27 second rise time and 17 second descent time. This enhanced hydraulic performance comes from optimized flow rates and power unit engineering designed specifically for high-throughput service environments.
Traditional inground lift systems often operate at slower cycle times, creating bottlenecks during busy service periods. Quick Cycle technology addresses this challenge by reducing wait times between vehicle positioning operations without sacrificing the smooth, controlled movement technicians need for safe operation.
This improves bay throughput in busy shops by minimizing the time vehicles spend transitioning between floor level and working height. Faster cycle times translate directly to more vehicles serviced per day without rushing technicians or compromising service quality.
Bench Mounted Controls (BMC)
The included Bench Mounted Controls provide an ergonomic control interface that can be positioned at the technician's workbench or service area. Unlike pendant controls that hang from the lift structure, BMC placement allows operators to control lift movement from their primary work position without leaving the immediate service area.
Standard pendant or wall-mounted controls often require technicians to step away from the vehicle during height adjustments. Bench mounted placement addresses this workflow inefficiency by integrating lift control directly into the service bay layout where technicians already work.
This enables faster height adjustments during multi-stage service operations like alignments, brake work, or undercarriage inspections. Technicians can make fine positioning adjustments without interrupting their workflow or moving between the vehicle and a remote control location.
8.5 Inch Chrome Pistons
The completion kit includes 8.5 inch diameter chrome pistons engineered for the EV1020's 10,000 lb capacity rating. Chrome plating provides a hardened, corrosion-resistant surface that maintains smooth operation over thousands of lift cycles while resisting the hydraulic fluid breakdown and scoring that can affect unplated components.
Piston surface quality directly impacts seal life and hydraulic efficiency. Rough or corroded piston surfaces accelerate seal wear, leading to fluid leaks and reduced lifting performance. Chrome plating addresses this wear mechanism by providing a consistently smooth bearing surface throughout the piston's service life.
This extends the service interval between seal replacements and maintains consistent lift performance over time. The larger 8.5 inch diameter also provides the surface area needed to support the EV1020's full 10,000 lb rated capacity with appropriate safety margins.
Complete Hydraulic Power Package
The EV10CK-BMC-QC consolidates all critical hydraulic and power components into a single kit: the hydraulic power unit, pistons, hardware box with fasteners and fittings, and bench mounted controls. This bundled approach ensures all components are matched and compatible with the EV1020 system architecture.
Purchasing hydraulic components separately creates compatibility risks and complicates warranty coverage. The completion kit approach eliminates guesswork by providing factory-matched components validated for the specific lift model and performance variant.
This simplifies the ordering process for new installations and ensures technicians have everything needed to complete the hydraulic system in one shipment. The hardware box includes the bolts, fittings, and fasteners required to connect all components without additional hardware orders.
Modular System Integration
The completion kit is designed as part of Challenger's modular EV1020 installation system, which separates the lift into three primary components: the pre-kit (foundation/cassette), the completion kit (hydraulics/power/controls), and the superstructure (arms/pads). This modularity allows facilities to stage installations or upgrade specific subsystems independently.
Traditional single-shipment lift installations require the entire system to arrive before any work can begin. The modular approach addresses scheduling constraints by allowing foundation work to proceed with the pre-kit while completion and superstructure components ship separately.
This enables phased installation projects where concrete work cures while remaining components are in transit. Facilities can also upgrade to Quick Cycle performance or different control configurations without replacing the entire lift system.
Applications & Use Cases
- New EV1020 Installations: Complete a new Challenger EV1020 inground lift installation with optimized Quick Cycle performance and ergonomic bench mounted controls for high-volume service operations.
- High-Throughput Service Centers: Professional shops and commercial garages that prioritize bay efficiency benefit from the faster cycle times that reduce vehicle transition delays between service operations.
- Dealership Service Departments: Automotive dealerships requiring consistent, efficient lift operation for warranty service, inspections, and general maintenance across multiple vehicle brands and sizes.
- Fleet Maintenance Facilities: Commercial fleet operations servicing trucks, vans, and passenger vehicles up to the 10,000 lb capacity rating where minimizing downtime directly impacts fleet availability.
- Upgrade Projects: Existing EV1020 installations upgrading from standard performance to Quick Cycle operation or transitioning to bench mounted controls for improved workflow.
Technical Specifications
| Specification | Value |
|---|---|
| Compatible Lift | Challenger EV1020 Inground Lift |
| Lift Capacity (System) | 10,000 lb |
| Piston Diameter | 8.5 inches |
| Piston Material | Chrome plated |
| Performance Variant | Quick Cycle (QC) |
| Control Type | Bench Mounted Controls (BMC) |
| Specification | Value |
|---|---|
| Rise Time (Approximate) | ~27 seconds |
| Descent Time (Approximate) | ~17 seconds |
| Component | Description |
|---|---|
| Hydraulic Components | Inground hydraulic/piston assembly |
| Chrome Pistons | 8.5 inch chrome plated pistons |
| Power Unit | Hydraulic power unit for Quick Cycle operation |
| Hardware Box | Bolts, fasteners, and fittings |
| Controls | Bench Mounted Controls (BMC) |
| Component | Notes |
|---|---|
| Pre-Kit (CSPK) | Foundation cassette and base tub assembly |
| Superstructure (EV1020SS) | Lifting arms and contact pads |
Installation Requirements
Required Components
- Pre-Kit/Base Tub: EV1020 pre-kit (CSPK) must be installed with foundation work completed and cured before completion kit installation
- Superstructure: EV1020 Superstructure (EV1020SS) required to complete the functional lift system
Power Requirements
- Electrical Supply: Per EV1020 lift documentation specifications
- Circuit Requirements: Verify electrical requirements with EV1020 installation manual
Installation Notes
- Professional Installation: Professional installation by qualified lift technicians recommended
- Permits: Verify local code compliance and permit requirements before installation
- Warranty Registration: Complete product registration with Challenger to activate warranty coverage
Shipping & Delivery
Freight Delivery
Shipping Method: Shipped via freight carrier.
Liftgate Service: Liftgate service typically not available for this shipment. Customer is responsible for unloading and staging components at delivery location.
Receiving Instructions
Inspection: Inspect all packages before signing the bill of lading. Note any visible damage on the BOL before the driver departs.
Unloading: Ensure appropriate equipment (forklift or loading dock) is available to receive freight shipment.
Warranty Coverage
Manufacturer Warranty
Coverage: Standard Challenger manufacturer warranty applies with proper product registration.
Registration: Complete warranty registration promptly after purchase to ensure coverage eligibility.
Dealer Terms: Specific warranty terms may vary by authorized dealer. Contact your dealer or Challenger directly for complete warranty details.
Ready to Complete Your EV1020 Installation?
Get expert guidance on the EV10CK-BMC-QC completion kit and EV1020 system components. Our team can help verify compatibility, confirm what's included, and answer technical questions about your installation.
Frequently Asked Questions
What is included in the Challenger EV10CK-BMC-QC completion kit?
The kit includes inground hydraulic components, 8.5 inch chrome pistons, the hydraulic power unit, a hardware box with bolts, fasteners, and fittings, and Bench Mounted Controls (BMC). It does not include the pre-kit foundation or superstructure, which are sold separately.
What lift is the EV10CK-BMC-QC compatible with?
The EV10CK-BMC-QC is designed specifically for the Challenger EV1020 10,000 lb capacity inground cassette-style lift. It is not compatible with other Challenger lift models or other manufacturers' inground systems.
What does Quick Cycle mean for the EV1020 completion kit?
Quick Cycle refers to the enhanced hydraulic performance that delivers faster lift operation. The QC variant provides approximately 27 second rise time and 17 second descent time, reducing vehicle transition delays compared to standard performance kits.
What are Bench Mounted Controls and how do they differ from standard controls?
Bench Mounted Controls (BMC) are lift controls designed to mount at a technician's workbench or service area rather than hanging from the lift structure as a pendant or mounting to a wall. This placement allows operators to adjust lift height without leaving their primary work position.
What other components do I need to complete an EV1020 installation?
In addition to this completion kit, you need the EV1020 Pre-Kit (CSPK) which includes the foundation cassette and base tub, and the EV1020 Superstructure (EV1020SS) which includes the lifting arms and contact pads. All three components are required for a functional lift system.
How is the EV10CK-BMC-QC shipped?
The completion kit ships via freight carrier. Liftgate service is typically not available, so you will need a forklift or loading dock to receive the shipment. Always inspect packages before signing the bill of lading and note any visible damage.
What warranty coverage applies to the EV10CK-BMC-QC?
The standard Challenger manufacturer warranty applies when the product is properly registered. Specific warranty terms and duration may vary, so contact your authorized dealer or Challenger directly for complete warranty details and registration requirements.
Can I install the EV10CK-BMC-QC myself?
Professional installation by qualified lift technicians is recommended. Inground lift installation involves hydraulic systems, electrical connections, and safety-critical components that require proper training and equipment to install correctly. Verify local permit requirements before beginning installation.
