Challenger EV1020LS-2 10,000 lb Inground Lift Set of 2, Tub and Frame Less Superstructure
The Challenger EV1020LS-2 delivers two complete EV1020 inground lift tub and frame assemblies in a single order, sold without superstructure for facilities that already have or are separately ordering arms, pads, and extensions. Each lift provides 10,000 lb capacity with a 2HP electric hydraulic motor driving a 68" stroke through an 8.5" chrome piston and a 38-second rise time. The sealed polymer cassette tub design contains all hydraulic fluid to eliminate environmental risk, while the 87" drive-thru clearance accommodates a wide range of vehicles from passenger cars to light trucks. ALI/ETL certified and engineered for professional service facilities expanding or replacing multi-bay inground lift installations.
Challenger EV1020LS-2 Inground Lift Features
Set of 2 Inground Lift Tub and Frame Assemblies
This listing delivers two complete EV1020 inground lift tub and frame assemblies, streamlining procurement for multi-bay installations, facility expansions, or simultaneous lift replacements. Ordering as a set simplifies logistics and ensures both units ship with matched components and serial numbers for coordinated installation scheduling.
10,000 lb Capacity with 8.5" Chrome Pistons
Each unit provides 10,000 lb total lifting capacity with 2,500 lb per arm, handling passenger cars, crossovers, SUVs, and light trucks. The 8.5" diameter chrome pistons deliver greater stability under load than smaller-bore competitive designs, while the chrome non-breathing ram-style cylinder construction resists corrosion and extends service life.
2HP Electric Hydraulic Power Unit
Each lift is powered by a reliable 2HP electric hydraulic motor that delivers a 38-second rise time with smooth, controlled operation. The standard power unit features a wall-mounted control with single push-button lift function and down release valve handle, providing straightforward operation for technicians across all skill levels.
Sealed Polymer Cassette Containment
Challenger EV Series inground lifts are fully contained in a sealed recycled polymer cassette tub that eliminates any risk of hydraulic fluid seeping into the surrounding soil or groundwater. This environmentally responsible design protects your facility from contamination liability while simplifying compliance with environmental regulations.
87" Drive-Thru Clearance
The 87" drive-thru clearance is among the widest in the inground lift category, accommodating full-size trucks, wide-bodied SUVs, and vehicles with extended mirrors or fender flares. The generous clearance minimizes tire pinching risk and provides confident drive-on access for a broad vehicle mix.
Over 50% More Bearing Contact Surface
Challenger EV Series lifts feature over 50% more bearing contact surface than competitive inground lifts, providing smoother operation and greater stability throughout the lift stroke. Enhanced raised wipers at both top and bottom of each bearing improve grease retention and minimize contaminant intrusion for reduced maintenance and longer component life.
Challenger EV1020LS-2 Inground Lift Applications
- Multi-Bay Service Facilities: The set-of-2 configuration is designed for facilities installing or replacing multiple inground lift positions simultaneously, reducing procurement complexity and ensuring matched equipment across bays.
- Fleet Maintenance Operations: The 10,000 lb capacity handles fleet service on passenger vehicles, vans, and light trucks. The standard 2HP motor provides dependable performance for steady-volume maintenance operations.
- Dealership Service Departments: ALI/ETL certified design meets professional standards and insurance requirements for warranty service. The flush-floor inground configuration provides a clean, modern service bay appearance.
- General Repair and Service Centers: The standard power configuration delivers reliable lift performance for shops with moderate daily throughput where consistent operation and long-term durability are prioritized over maximum cycle speed.
- New Construction and Facility Expansion: The Less Superstructure (LS) configuration allows facilities to specify superstructure components separately, accommodating custom arm configurations or phased installation schedules.
Challenger EV1020LS-2 Specifications
Specifications listed are per individual lift unit. This listing includes 2 lift units.
| Specification | Value |
|---|---|
| Quantity | Set of 2 lift units |
| Lifting Capacity (Per Lift) | 10,000 lb (4,536 kg) |
| Capacity Per Arm | 2,500 lb (1,134 kg) |
| Stroke | 68" (1,727 mm) |
| Rise Height | 74" (1,880 mm) |
| Rise Time | 38 seconds |
| Motor | 2 HP (Standard) |
| Lock Engagement | Every 3" |
| Specification | Value |
|---|---|
| Overall Width | 97" (2,464 mm) |
| Drive-Thru Clearance | 87" (2,210 mm) |
| Piston Diameter | 8.5" (216 mm) |
| Specification | Value |
|---|---|
| Electrical Service | 208-230V, 60Hz, single phase |
| Motor Rating | 2 HP (Standard) |
| Air Supply Requirement | 90-120 PSI |
Note: Rise height of 74" is measured at the top of the piston without superstructure. With superstructure installed, effective rise height increases based on the adapter configuration used. Superstructure is sold separately for this LS (Less Superstructure) model.
Challenger EV1020LS-2 Installation Requirements
Electrical Requirements
Power: 208-230V, 60Hz, single phase per lift unit. The standard EV1020 requires a dedicated 2HP motor circuit with 30A service for each lift. A licensed electrician must install and verify the electrical supply meets all local codes and manufacturer specifications.
Concrete Pit Construction
Foundation: Inground installation requires proper concrete pit construction per Challenger specifications. Concrete must meet minimum PSI requirements with proper reinforcement. The sealed polymer cassette tub is installed into the prepared pit before the completion kit and superstructure are assembled. Consult the installation manual for detailed pit dimensions and preparation requirements.
Pneumatic Requirements
Air Supply: 90-120 PSI compressed air required for lock release operation on each lift unit. Ensure your shop air system can maintain adequate pressure and volume for consistent operation across both lifts simultaneously.
Professional Installation Required
Professional installation by a qualified lift installer is required. Inground lift installation involves concrete work, electrical connections, and hydraulic system setup that must be performed correctly for safe operation and warranty coverage. Challenger can recommend certified installers in your area.
What's Included with the Challenger EV1020LS-2
This listing includes 2 complete lift tub and frame assemblies. Each unit contains the following:
- Challenger EV1020 inground lift assembly with 2HP electric hydraulic power unit
- Sealed polymer cassette tub
- 8.5" chrome pistons
- Chrome non-breathing ram-style cylinders
- Enhanced raised wipers (top and bottom)
- Mechanical safety locks (engaging every 3")
- Standard wall-mounted power controls
- Installation and operation manual
Superstructure Required (Sold Separately): This is a Less Superstructure (LS) model. The EV1020SS superstructure kit must be purchased separately for each lift unit. The superstructure includes 3-stage front and rear arms, double telescoping screw pads, standard and medium extensions, high extensions, and frame engaging truck adapters.
Optional Accessories: Quick Cycle pump upgrade (QC), bench mount controls (BMC), StayDry automatic condensate removal kit (SD100), drive-on pad conversion (XP9), additional stack adapter extension kits, and 6" stack adapter extensions available separately.
Not Included: Superstructure (arms, pads, extensions, frame adapters), concrete pit construction, electrical wiring and installation, compressed air supply system, and professional installation labor.
Challenger EV1020LS-2 Shipping and Delivery
Freight Shipping
Coverage: Free freight shipping to commercial addresses in the 48 contiguous United States. Lead Time: Contact sales for current lead times on set-of-2 orders. International: Contact sales for international shipping quotes and availability.
Delivery Requirements
Unloading: Forklift or loading dock required for unloading. Inground lift components ship on heavy pallets and require equipment capable of handling the shipping weight. Delivery Type: Curbside delivery to commercial addresses is standard. Inspection: Inspect all packages for damage before signing the bill of lading. Document and photograph any visible damage on the delivery receipt immediately.
Returns
Returns accepted within 30 days of delivery. Product must be unopened in original packaging with proof of purchase. A 20% restocking fee applies to all returns. Buyer is responsible for return freight costs.
Challenger EV1020LS-2 Warranty
Challenger Lifts Warranty Coverage
Challenger Lifts stands behind their American-engineered inground lift products with comprehensive warranty protection.
- 5 Years: Structural components including cassette tub, plungers, and main frame assembly
- 2 Years: Functional parts including power units, cylinders, hoses, cables, and controls
- 1 Year: Electrical components and accessories
Extended Warranty: An optional extended warranty is available for purchase within 30 days of the lift invoice, extending functional parts coverage by an additional 3 years (5 years total).
Requirements: Warranty coverage requires proper installation according to manufacturer specifications, use within rated capacity, and adherence to recommended maintenance procedures. Warranty registration must be completed within 30 days of installation at challengerlifts.com. See warranty document for complete terms and exclusions.
Documents
Click to open in a new tab.
Questions About the Challenger EV1020LS-2?
Our equipment specialists can help with installation planning, superstructure selection, and multi-bay configuration for your facility.
Challenger EV1020LS-2 Inground Lift FAQ
What does "Less Superstructure" (LS) mean?
Less Superstructure means this listing includes the complete inground lift tub and frame assemblies (cassette tub, pistons, power unit, controls, and safety locks) without the superstructure assembly. The EV1020SS superstructure kit, which includes 3-stage front and rear arms, double telescoping screw pads, extensions, and frame engaging adapters, must be purchased separately for each lift unit to achieve a fully operational lift system.
What does "Tub and Frame" refer to?
Tub and Frame refers to the core inground lift components: the sealed polymer cassette tub that sits in the concrete pit and the structural frame assembly that houses the hydraulic cylinder, pistons, bearings, and safety locks. Together with the power unit and controls (included), these components form the complete lift mechanism. The superstructure (arms, pads, and extensions that contact the vehicle) is the only major component group not included.
How many lift units are included in this listing?
This listing includes 2 complete EV1020 inground lift tub and frame assemblies. Each unit is a self-contained inground lift with its own 2HP power unit, 8.5" chrome pistons, sealed polymer cassette tub, mechanical safety locks, and wall-mounted controls. Both units ship together for coordinated multi-bay installation.
What is the difference between this standard model and the EV1020-QC?
The standard EV1020 uses a 2HP motor with a standard pump delivering a 38-second rise time, while the EV1020-QC uses the same 2HP motor with an upgraded pump (4cc vs 2.5cc) that achieves a 27-second rise and 17-second lowering time. The standard model is well suited for facilities with moderate daily throughput, while the QC model targets high-volume environments where over 40% faster lift cycles directly impact revenue.
What is the lifting capacity of each unit?
Each EV1020 lift unit has a total lifting capacity of 10,000 lb with 2,500 lb capacity per arm. This accommodates passenger cars, crossovers, SUVs, and light trucks. The 8.5" chrome pistons provide greater stability under load compared to smaller-bore competitive designs.
What is the difference between the EV1020 and EV1220?
The EV1020 has a 10,000 lb capacity with 2,500 lb per arm and a 97" overall width, while the EV1220 has a 12,000 lb capacity with 3,000 lb per arm and a 115" overall width. Both share the same 87" drive-thru clearance and 8.5" chrome pistons. The EV1020 offers a more compact footprint ideal for standard passenger vehicle service, while the EV1220 handles heavier commercial vehicles.
What electrical power does each lift require?
Each standard EV1020 lift unit requires 208-230V, 60Hz, single phase power with a dedicated 2HP motor circuit and 30A service. Since this is a set of 2 lifts, your facility will need 2 separate electrical circuits meeting these specifications. A licensed electrician must install and verify electrical supply for each unit.
What superstructure do I need to complete the lift?
Each lift unit requires one EV1020SS superstructure kit. The superstructure includes 3-stage front and rear arms with reach from 19.625" to 42.125", double telescoping screw pads adjustable from 3.875" to 6", standard and medium extensions, high extensions, and frame engaging truck adapters. Frame engaging adapters are required when lifting vehicles with frame construction.
Is compressed air required?
Yes, each lift unit requires compressed air at 90-120 PSI for the mechanical lock release mechanism. Ensure your shop air system can provide adequate pressure and volume for consistent operation across both lifts, especially during simultaneous use in adjacent bays.
Is this lift ALI/ETL certified?
Yes, the Challenger EV1020 carries both ALI (Automotive Lift Institute) and ETL certification, validating that the lift meets recognized safety and performance standards. This third-party certification provides documented compliance appropriate for professional service facilities and insurance requirements.
What warranty coverage is included?
Challenger provides a 5-year warranty on structural components, 2-year warranty on functional parts (power units, cylinders, hoses, controls), and 1-year warranty on electrical components. An optional extended warranty adding 3 years of functional parts coverage is available within 30 days of purchase. Warranty registration must be completed within 30 days of installation.
What maintenance does this lift require?
Challenger EV Series inground lifts require quarterly greasing of bearings, which is less frequent than competitive models that require monthly maintenance. Regular inspection of safety locks, hydraulic fluid levels, wipers, and piston condition should follow the maintenance schedule in the installation manual. The optional StayDry kit (SD100) automates condensate removal from the cassette tub.
California Proposition 65 Warning
WARNING: This product can expose you to chemicals including styrene and vinyl chloride, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit www.p65warnings.ca.gov.
