Challenger Lift Adapters for Low-Clearance Vehicles - CLHM-EL90-LP Overview
Some vehicles just don't play nice with standard lift setups. Low ground clearance, aggressive body kits, and slammed suspensions can make a typical end lift adapter a liability. The Challenger CLHM-EL90-LP Lower Profile End Lift Adapter Set is built specifically for that situation - it drops the lifting point lower so you can get under vehicles that would otherwise be off-limits for your mobile column lift.
This adapter is part of the CLHM Series accessory lineup, and it's the right call when you're working with vehicles where standard car lift adapters can't make solid contact without risking contact with the rocker panels or underbody. The minimum starting height of 11" and a lift pad spread that adjusts from 6" to 44.5" center-to-center gives you real versatility across different vehicle platforms - all from a single adapter set that weighs 56 lbs and measures 49" long.
If your shop is running a mix of daily drivers, performance cars, or anything with limited underbody clearance, these 2 post lift adapters for the CLHM mobile column system let you keep those jobs in-house instead of turning them away. Genuine Challenger lift parts, direct support, free shipping to the lower 48. You're covered.
Specifications
| Part Number | CLHM-EL90-LP |
| Overall Length | 49" |
| Overall Width | 10.125" |
| Min Starting Height | 11" |
| Min Lift Pad Spread (Center to Center) | 6" |
| Max Lift Pad Spread (Center to Center) | 44.5" |
| Min Lift Pad Clearance from Cross Member | 1.8" |
| Max Lift Pad Clearance from Cross Member | 3.65" (12.4") |
| Lift Pad Opening | 4.5" |
| Weight | 56 lbs |
| Compatible System | Challenger CLHM Mobile Column Series |
What's Included
Call to confirm included accessories.
Applications
The CLHM-EL90-LP is the adapter you reach for when standard auto lift adapters won't make the cut. Here's where it earns its place in your shop:
Sports cars and modified vehicles with minimal ground clearance need a lower lift point. The 11" minimum starting height and reduced pad-to-cross-member clearance make safe contact possible where standard adapters can't reach.
The 44.5" maximum lift pad spread accommodates a wide range of vehicle widths. You're not locked into a narrow target zone when you're positioning under wider platforms like trucks or SUVs.
If your shop handles everything from compacts to full-size vehicles, the adjustable spread range means this adapter works across your entire bay rotation without swapping setups constantly.
Paired with the Challenger CLHM mobile column system, these 2 post lift wheel adapters and end lift accessories round out your lifting capability for jobs that require a stable, low-profile pickup point.
Shipping
This item ships free to the contiguous lower 48 states. Our team coordinates the shipment and helps manage scheduling details. Need a specific delivery window or other arrangements? Contact us before ordering so we can confirm the best delivery setup.
Warranty
The CLHM-EL90-LP is covered under the Challenger Lifts accessory warranty: 90 days on accessories and replacement parts.
This warranty applies to the original purchaser only and is non-transferable. Coverage requires that the adapter be installed, used, and maintained according to Challenger Lifts specifications. Use of unapproved parts or accessories will void coverage. Warranty registration may be required after purchase - refer to included documentation for details.
This warranty does not cover normal wear and tear, damage from improper installation or misuse, or repairs made by anyone other than a CLI authorized service representative.
Questions Before You Buy?
Our team can help you confirm fitment with your CLHM system and make sure you're ordering the right adapter for your application. Call us at (855) 498-2147.
Frequently Asked Questions
What mobile column lift system is the CLHM-EL90-LP compatible with?
The CLHM-EL90-LP is part of the Challenger CLHM mobile column series accessory lineup. If you're running a different lift system, call us at (855) 498-2147 to confirm compatibility before ordering.
Why do I need a lower profile adapter instead of a standard end lift adapter?
Standard adapters have a higher minimum starting height that can conflict with vehicles that have limited ground clearance or low-hanging underbody components. The CLHM-EL90-LP has a minimum starting height of 11" and a reduced lift pad-to-cross-member clearance (as low as 1.8"), which allows it to make solid contact on vehicles where a standard adapter can't safely engage.
What is the lift pad spread range on the CLHM-EL90-LP?
The lift pad spread adjusts from 6" to 44.5" center-to-center. That range covers compact cars with tight pinch-weld spacing as well as wider platforms like full-size trucks and SUVs.
How much does this adapter weigh, and will it affect my column lift capacity?
The CLHM-EL90-LP weighs 56 lbs. For questions about how accessory weight affects your specific CLHM system's rated capacity, contact us at (855) 498-2147 and we can walk through the details with you.
Does this adapter ship free?
Yes - the CLHM-EL90-LP ships free to addresses in the contiguous lower 48 states. If you need specific delivery arrangements, contact us before placing your order.
What warranty does the CLHM-EL90-LP carry?
As a Challenger Lifts accessory, the CLHM-EL90-LP is covered by a 90-day warranty on parts. Coverage is for the original purchaser only and requires proper installation and use per Challenger Lifts specifications. Warranty registration may be required - refer to included documentation for details.
What is the lift pad opening size?
The lift pad opening is 4.5". This determines what size lift pads can be seated into the adapter. Confirm pad compatibility with your existing CLHM setup before ordering - call (855) 498-2147 if you have questions.
Can I use this adapter on a 2-post lift instead of a mobile column system?
The CLHM-EL90-LP is part of the Challenger CLHM mobile column accessory line and is spec'd for that system. It is not a standard 2-post lift adapter. If you need car lift adapters for a 2-post application, call us at (855) 498-2147 and we'll point you to the right product.
