BRANICK OEM Gas Spring Assembly, 01-0203 for TC400 Tire Cart

BRANICK OEM Gas Spring Assembly, 01-0203 for TC400 Tire Cart

Q: Will this gas spring fit my Branick TC400 tire cart? A: Yes, the Branick 01-0203 is engineered exclusively for TC400 tire carts with exact OEM specifications. The 3.15-inch stroke length, 9.6-inch extended length, and M6-1.00 threaded end fittings provide direct drop-in compatibility with all TC400 models. This gas spring will not fit other Branick cart models or universal tire handling equipment.

Q: Will this gas spring fit my Branick TC400 tire cart? Yes, the Branick 01-0203 is engineered exclusively for TC400 tire carts with exact OEM specifications. The 3.15-inch stroke length, 9.6-inch extended length, and M6-1.00 threaded end fittings provide direct drop-in compatibility with all TC400 models. This gas spring will not fit other Branick cart models or universal tire handling equipment.

Q: How do I know if my TC400 gas spring needs replacement? A: Replace your gas spring if you notice slow or weak arm closure, insufficient clamping pressure on tire stacks, the cart arm drifting down when positioned, or difficulty maintaining tire stack position during handling. These symptoms indicate the internal seals have worn and force output has decreased below the 80 lb specification.

Q: How do I know if my TC400 gas spring needs replacement? Replace your gas spring if you notice slow or weak arm closure, insufficient clamping pressure on tire stacks, the cart arm drifting down when positioned, or difficulty maintaining tire stack position during handling. These symptoms indicate the internal seals have worn and force output has decreased below the 80 lb specification.

Q: What tools do I need to install this gas spring assembly? A: Installation requires only basic hand tools for removing and installing M6 fasteners, typically a socket wrench or combination wrench set. No specialized hydraulic tools, compressed air equipment, or system bleeding procedures are needed. Support the tire cart arms during replacement as the gas spring operates under pressure. Most technicians complete installation in 15-30 minutes per unit.

Q: What tools do I need to install this gas spring assembly? Installation requires only basic hand tools for removing and installing M6 fasteners, typically a socket wrench or combination wrench set. No specialized hydraulic tools, compressed air equipment, or system bleeding procedures are needed. Support the tire cart arms during replacement as the gas spring operates under pressure. Most technicians complete installation in 15-30 minutes per unit.

Q: Is this an OEM Branick part or aftermarket replacement? A: This is a genuine OEM replacement part manufactured to Branick Industries specifications for the TC400 tire cart. The part number 01-0203 matches original equipment specifications with factory-engineered dimensions, force ratings, and M6-1.00 thread fittings. It provides direct drop-in compatibility without modifications or adapters required for fitment.

Q: Is this an OEM Branick part or aftermarket replacement? This is a genuine OEM replacement part manufactured to Branick Industries specifications for the TC400 tire cart. The part number 01-0203 matches original equipment specifications with factory-engineered dimensions, force ratings, and M6-1.00 thread fittings. It provides direct drop-in compatibility without modifications or adapters required for fitment.

$66.99

Product variants

$ Save 3% with ACH / Wire Payment — call for details

Authorized Online Dealer direct manufacturer relationship
No Sales Tax outside PA where applicable
Authorized Dealer Price Match verification required
Fast Delivery some products may have lead times
Manufacturer Warranty included with purchase
Questions? +1 (855) 498-2147

OEM Replacement Gas Spring - Branick TC400 Tire Cart (01-0203 Assembly)

When your Branick TC400 tire cart loses its auto-closing grip, the Branick 01-0203 gas spring assembly restores factory performance in 15-30 minutes. This 6×15 OEM gas spring delivers 80 lb force through a 3.15-inch stroke, automatically clamping tire stacks when you release the foot pedal. Professional tire shops, dealerships, and fleet maintenance facilities use this black nitride-coated assembly to maintain hands-free operation across passenger and light truck tires up to 400 lbs.

Manufactured to exact OEM specifications with M6-1.00 threaded end fittings, this direct drop-in replacement requires only basic hand tools and no hydraulic modifications. Backed by Branick Industries' 100+ years of tire equipment engineering, the corrosion-resistant steel construction handles tire shop environments with exposure to lubricants, oils, and temperature fluctuations.

Key Features and Benefits

Factory-Exact TC400 Engineering - The 3.15-inch stroke length and 9.6-inch extended length match TC400 arm geometry, delivering consistent auto-closing force across the cart's 20-37 inch adjustable cradle range. M6-1.00 threaded end fittings install directly without adapters or modifications.

Corrosion-Resistant Construction - Black nitride rod coating and steel tube construction maintain performance in tire shop environments with exposure to moisture, tire lubricants, and oils. Designed for professional facilities performing 20-50+ tire changes daily.

Hands-Free Operation - The 80 lb force rating automatically grips tire stacks when the foot pedal releases, keeping both hands free for tire positioning. Eliminates manual clamp tightening and prevents arm collapse from worn springs.

Applications

Direct replacement for worn gas springs in Branick TC400 tire carts.
Automotive service centers and tire retail facilities handling passenger car and light truck tires.
Fleet maintenance operations requiring reliable hands-free clamping equipment.
High-volume shops performing 20-50+ tire changes daily with tires up to 35 inches diameter.

Technical Specifications

Branick 01-0203 Gas Spring Specifications
Specification	Value
Part Number	01-0203
Compatibility	Branick TC400 Tire Cart (exclusive fitment)
Assembly Type	6×15 OEM gas spring
Stroke Length	3.15 in (80.01 mm)
Extended Length	9.6 in (243.84 mm)
Force Rating	80 lb (356 N)
Rod Diameter	0.235 in (5.97 mm)
Tube Diameter	0.591 in (15.01 mm)
Thread Specification	M6-1.00 (M6 × 1.0 mm pitch)
Rod Finish	Black nitride-coated steel
Tube Material	Steel construction
Country of Origin	South Korea

Restore Your TC400's Performance

This OEM gas spring assembly ships from authorized Branick distributors and installs in under 30 minutes with basic tools.

Frequently Asked Questions

Will this gas spring fit my Branick TC400 tire cart?

Yes, the Branick 01-0203 is engineered exclusively for TC400 tire carts with exact OEM specifications. The 3.15-inch stroke length, 9.6-inch extended length, and M6-1.00 threaded end fittings provide direct drop-in compatibility with all TC400 models. This gas spring will not fit other Branick cart models or universal tire handling equipment.

How do I know if my TC400 gas spring needs replacement?

Replace your gas spring if you notice slow or weak arm closure, insufficient clamping pressure on tire stacks, the cart arm drifting down when positioned, or difficulty maintaining tire stack position during handling. These symptoms indicate the internal seals have worn and force output has decreased below the 80 lb specification.

What tools do I need to install this gas spring assembly?

Installation requires only basic hand tools for removing and installing M6 fasteners, typically a socket wrench or combination wrench set. No specialized hydraulic tools, compressed air equipment, or system bleeding procedures are needed. Support the tire cart arms during replacement as the gas spring operates under pressure. Most technicians complete installation in 15-30 minutes per unit.

Is this an OEM Branick part or aftermarket replacement?

This is a genuine OEM replacement part manufactured to Branick Industries specifications for the TC400 tire cart. The part number 01-0203 matches original equipment specifications with factory-engineered dimensions, force ratings, and M6-1.00 thread fittings. It provides direct drop-in compatibility without modifications or adapters required for fitment.
