American Forge and Foundry 10 Ton Jack - Long Chassis Heavy Duty Floor Jack
You're working on a transit bus, a long-bed semi, or a piece of heavy agricultural equipment. The chassis hangs out far past the axle, the belly sits low, and a standard floor jack can't get close to where it needs to be. That's exactly the problem the American Forge & Foundry AFF 3130 was built to solve. This 10 ton heavy duty floor jack stretches 61 inches end to end, giving you the reach to get under vehicles with long overhangs without fighting the geometry of the equipment you're lifting.
The 3130 bottoms out at just 7 inches, so getting under tight clearances isn't a battle. A foot-operated pump means you're not hunched over working the handle while trying to position yourself under the vehicle. You pump with your foot, you move freely, you get the job done faster. Automatic overload safety valves protect the jack and protect your crew if something unexpected happens mid-lift. That's not a nice-to-have on a commercial floor jack handling 20,000 lbs of load.
Swivel casters let you maneuver in tight shop bays without dragging the jack sideways. The extra-wide rear stance keeps things planted when you're fully loaded. A handle-mounted control lever locks the handle in one of three positions so you're working at the angle that makes sense for your setup. This is a commercial hydraulic floor jack built for shops that lift heavy equipment all day, not a weekend warrior tool.
We ship the AFF 3130 free to the lower 48, and our team is here if you have questions before or after the sale. Call us directly and you're talking to someone who knows the product.
Specifications
| Model | 3130 |
| Capacity | 10 Tons (20,000 lbs) |
| Low Height | 7" |
| High Height | 23" |
| Chassis Length | 61" |
| Front Width | 13" |
| Rear Width | 18" |
| Pump Operation | Foot-operated |
| Handle Positions | 3 (handle-mounted control lever) |
| Safety | Automatic overload safety valves |
| Casters | Swivel |
| Ship Weight | 366 lbs |
What's Included
Call to confirm included accessories.
Applications - Who This Jack Is For
The AFF 3130 is purpose-built for heavy-duty commercial and industrial lifting environments. If your shop handles any of the following, this is the long chassis floor jack for the job.
Buses sit low and stretch long. The 61-inch chassis gets underneath where a standard jack can't reach, and 10 tons of capacity means you're not under-lifting the vehicle.
Long-bed and heavy-duty trucks with extended overhangs demand extended reach. The foot-operated pump keeps your hands free while you position under the frame.
Tractors, combines, and implements are heavy and awkward to position under. The extra-wide rear stance keeps the jack stable when you're working with uneven load distribution.
Heavy machinery used in construction and industrial operations often requires access to low, hard-to-reach points under the chassis. This commercial grade floor jack handles those applications reliably.
Model Comparison - Long Chassis Jack Family
American Forge & Foundry offers more than one long chassis jack. Here's how the 3130 stacks up against the higher-capacity option in the lineup so you can pick the right tool for your shop's load requirements.
| Model | Capacity | Chassis Length | Type |
|---|---|---|---|
| 3130 (This Model) | 10 Tons | 61" | Long Chassis Floor Jack |
| 3140 | 20 Tons | - | Long Chassis Service Jack |
If your shop regularly lifts equipment pushing or exceeding 20,000 lbs, the Model 3140 is worth a look. For most commercial truck, bus, and agricultural applications under that threshold, the 3130 is the right fit. Call us and we'll help you confirm which model matches your typical load.
Product Video
Shipping
Free Shipping To Lower 48. Due to the ship weight of 366 lbs, this jack ships via freight. Contact us before ordering if you have questions about delivery logistics or need to confirm freight access at your location.
Warranty
Limited Warranty - 1 Year
American Forge & Foundry warrants this equipment to the final purchaser to be free from operating defects in material and workmanship for one year from the date of purchase. If the jack is determined to be defective during the warranty period, AFF will, at its option, repair or replace it at no charge provided the unit is shipped prepaid with proof of purchase to AFF or an authorized Field Service Depot.
This warranty does not cover damage caused by accident, overload, or abuse, nor does it apply to products that have been altered or used with attachments not expressly recommended by American Forge & Foundry. The seller's sole obligation is to repair or replace defective parts. No other express or implied warranties apply.
Note: Torque wrench calibration, where applicable, is warranted for 90 days from purchase.
Documents
Click to open in a new tab.
Sale Sheet
Ready to Order or Have Questions?
Call us at (855) 498-2147 and we'll get you taken care of. Our team knows these jacks and can help you confirm the right model for your shop's application before you buy.
Frequently Asked Questions
What types of vehicles and equipment is the AFF 3130 designed to lift?
The AFF 3130 is built for heavy-duty commercial and industrial applications, including bus and transit fleets, long-haul trucks, agricultural equipment like tractors and combines, and heavy construction machinery. Its 61-inch chassis length and 7-inch low height are specifically intended for vehicles with long overhangs or tight undercarriage clearances that a standard floor jack can't reach.
What is the minimum clearance needed to use this jack?
The AFF 3130 has a minimum height of 7 inches, meaning you need at least 7 inches of clearance under the lift point to get the jack in position. It raises to a maximum height of 23 inches. If your application requires lower entry clearance, call us to discuss your options before ordering.
Does this jack ship for free?
Yes, the AFF 3130 ships free to the lower 48 states. Because the unit weighs 366 lbs, it ships via freight carrier. If you have questions about delivery requirements or freight access at your facility, call us at (855) 498-2147 before placing your order.
What warranty comes with the AFF 3130?
American Forge & Foundry covers the 3130 with a one-year limited warranty against defects in material and workmanship. If a defect is found during that period, AFF will repair or replace the unit at no charge, provided it's returned prepaid with proof of purchase. The warranty does not cover damage from overload, accident, abuse, or use of non-approved attachments.
Is the 3130 the right model or should I be looking at the 3140?
The 3130 handles up to 10 tons (20,000 lbs) and is the right fit for most commercial truck, bus, and agricultural applications in that range. The Model 3140 steps up to 20 tons for heavier equipment. If you're unsure which capacity covers your typical loads, call us at (855) 498-2147 and we'll help you decide.
